gameboy_worlds.emulation.parser

  1import warnings
  2
  3warnings.filterwarnings("ignore", message=".*SDL2 binaries.*")
  4# To suppress pyBoy SDL2 warnings on some systems
  5from pyboy import PyBoy
  6from abc import ABC, abstractmethod
  7from gameboy_worlds.utils import (
  8    log_error,
  9    log_warn,
 10    verify_parameters,
 11    show_frames,
 12    import_cv2,
 13)
 14
 15
 16import numpy as np
 17
 18import os
 19from typing import Dict, Tuple, Optional, List, Union
 20from PIL import Image
 21
 22
 23def _get_proper_regions(
 24    override_regions: List[Tuple[str, int, int, int, int]],
 25    base_regions: List[Tuple[str, int, int, int, int]],
 26) -> List[Tuple[str, int, int, int, int]]:
 27    """
 28    Merges base regions with override regions, giving precedence to override regions.
 29
 30    :param override_regions: List of override region tuples.
 31    :type override_regions: List[Tuple[str, int, int, int, int]]
 32    :param base_regions: List of base region tuples.
 33    :type base_regions: List[Tuple[str, int, int, int, int]]
 34    :return: Merged list of region tuples.
 35    :rtype: List[Tuple[str, int, int, int, int]]
 36    """
 37    if len(override_regions) == 0:
 38        return base_regions
 39    proper_regions = override_regions.copy()
 40    override_names = [region[0] for region in override_regions]
 41    for region in base_regions:
 42        if region[0] in override_names:
 43            continue
 44        proper_regions.append(region)
 45    return proper_regions
 46
 47
 48class NamedScreenRegion:
 49    """
 50    Saves a reference to a named screen region (always a rectangle) for easy access.
 51    """
 52
 53    def __init__(
 54        self,
 55        name: str,
 56        start_x: int,
 57        start_y: int,
 58        width: int,
 59        height: int,
 60        parameters: dict,
 61        *,
 62        target_path: Optional[str] = None,
 63        multi_target_paths: Optional[Dict[str, str]] = None,
 64    ):
 65        """
 66        Initializes a named screen region.
 67
 68        Parameters:
 69            name (str): The name of the screen region.
 70            start_x (int): The starting x-coordinate of the region in pixel space of the full resolution game screen.
 71            start_y (int): The starting y-coordinate of the region in pixel space of the full resolution game screen.
 72            width (int): The width of the region in pixels.
 73            height (int): The height of the region in pixels.
 74            target (str): Optional path to a .npy file containing a screen capture of this region. Non-existent paths are only allowed if parameters['debug_mode'] (from configs/project_vars.yaml) is set to True.
 75            multi_target_paths (Optional[Dict[str, str]]): Optional dictionary containing multiple possible paths to .npy files for this region. Keys are arbitrary strings, values are paths to .npy files. If provided, this will override target_path and force it None. Allows using the same region for multiple target images.
 76        """
 77        if not isinstance(name, str):
 78            log_error(f"name must be a string. Found {type(name)}", parameters)
 79        if len(name.split()) > 1:
 80            log_error(
 81                f"name must be a single word with no spaces. Found {name}", parameters
 82            )
 83        if "," in name:
 84            log_error(f"name cannot contain commas. Found {name}", parameters)
 85        self.name = name
 86        """ Name of the screen region. """
 87        if (
 88            not isinstance(start_x, int)
 89            or not isinstance(start_y, int)
 90            or not isinstance(width, int)
 91            or not isinstance(height, int)
 92        ):
 93            log_error(
 94                f"start_x, start_y, width, and height must be integers. Found {type(start_x)}, {type(start_y)}, {type(width)}, {type(height)}",
 95                parameters,
 96            )
 97        self.start_x = start_x
 98        """ The starting x-coordinate of the region. """
 99        self.start_y = start_y
100        """ The starting y-coordinate of the region. """
101        self.width = width
102        """ The width of the region. """
103        self.height = height
104        """ The height of the region. """
105        self._parameters = parameters
106        self.target_path = None
107        """ Path to npy file of a screen capture that we will be comparing this region against. """
108        self.target: Optional[np.ndarray] = None
109        """ Numpy array of the target image for this region. """
110        self.multi_target_paths = multi_target_paths
111        self.multi_targets = None
112        """ Dictionary of multiple target paths for this region. """
113        if multi_target_paths is not None:
114            self.multi_targets = {}
115            for key, path in multi_target_paths.items():
116                if not isinstance(key, str):
117                    log_error(
118                        f"multi_target_paths keys must be strings. Found {type(key)}",
119                        parameters,
120                    )
121                if len(key.split()) > 1:
122                    log_error(
123                        f"multi_target_paths keys must be single words with no spaces. Found {key}",
124                        parameters,
125                    )
126                if "," in key:
127                    log_error(
128                        f"multi_target_paths keys cannot contain commas. Found {key}",
129                        parameters,
130                    )
131                self.multi_targets[key] = self._sanity_load_target(path)
132        else:
133            if target_path is not None:
134                self.target_path = target_path
135                self.target = self._sanity_load_target(target_path)
136
137    def _sanity_load_target(self, target_path: str) -> Optional[np.ndarray]:
138        """
139        Loads the target image from the given path.
140
141        :param target_path: Path to the .npy file containing the target image.
142        :type target_path: str
143        :return: The loaded target image as a numpy array, or None if the file does not exist and debug_mode is enabled.
144        :rtype: ndarray[_AnyShape, dtype[Any]] | None
145        """
146        if not target_path.endswith(".npy"):
147            target_path = target_path + ".npy"
148        if not os.path.exists(target_path):
149            if not self._parameters["debug_mode"]:
150                log_error(
151                    f"Target file {target_path} does not exist. This is only allowed in debug_mode (can be set in configs/project_vars.yaml)",
152                    self._parameters,
153                )
154            else:
155                log_warn(
156                    f"Target file {target_path} does not exist. Continuing since debug_mode is enabled.",
157                    self._parameters,
158                )
159            return None
160        else:
161            target = np.load(target_path)
162            return target
163
164    def get_end_x(self) -> int:
165        """
166        Returns the end x-coordinate of the named screen region.
167
168        Returns:
169            int: The end x-coordinate of the named screen region.
170        """
171        return self.start_x + self.width
172
173    def get_end_y(self) -> int:
174        """
175        Returns the end y-coordinate of the named screen region.
176        Returns:
177            int: The end y-coordinate of the named screen region.
178        """
179        return self.start_y + self.height
180
181    def get_corners(self) -> Tuple[int, int, int, int]:
182        """
183        Returns the corners of the named screen region as (start_x, start_y, end_x, end_y).
184
185        :return: The corners of the named screen region.
186        :rtype: Tuple[int, int, int, int]
187        """
188        return (self.start_x, self.start_y, self.get_end_x(), self.get_end_y())
189
190    def __str__(self) -> str:
191        return f"NamedScreenRegion(name={self.name}, start_x={self.start_x}, start_y={self.start_y}, width={self.width}, height={self.height})"
192
193    def __repr__(self) -> str:
194        return self.__str__()
195
196    def compare_against_target(
197        self, reference: np.ndarray, strict_shape: bool = True
198    ) -> float:
199        """
200        Computes the Absolute Error (AE) between the given reference image and the target image.
201
202        :param reference: The reference image to compare.
203        :type reference: np.ndarray
204        :param strict_shape: Whether to error out if the array shapes do not match.
205        :type strict_shape: bool
206        :return: The Absolute Error (AE) between the reference and target images.
207        :rtype: float
208        """
209        if self.target is None:
210            if self._parameters["debug_mode"]:
211                return float("inf")
212            log_error(
213                f"No target image set for NamedScreenRegion {self.name}. Cannot compare.",
214                self._parameters,
215            )
216        if reference.shape != self.target.shape:
217            if strict_shape:
218                log_error(
219                    f"Reference image shape {reference.shape} does not match target image shape {self.target.shape} for NamedScreenRegion {self.name}.",
220                    self._parameters,
221                )
222            else:
223                return float("inf")
224        diff = np.abs(reference.astype(np.float32) - self.target.astype(np.float32))
225        mae = np.mean(diff)
226        return mae
227
228    def compare_against_multi_target(
229        self, target_name: str, reference: np.ndarray, strict_shape: bool = True
230    ) -> float:
231        """
232         Computes the Absolute Error (AE) between the given reference image and one of the multiple target images.
233
234        :param self: Description
235        :param target_name: The name of the target image to compare against.
236        :type target_name: str
237        :param reference: The reference image to compare.
238        :type reference: np.ndarray
239        :param strict_shape: Whether to error out if the array shapes do not match.
240        :type strict_shape: bool
241        :return: The Absolute Error (AE) between the reference and specified target images.
242        :rtype: float
243        """
244        if self.multi_targets is None or target_name not in self.multi_targets:
245            log_error(
246                f"No multi target image set for NamedScreenRegion {self.name} with target name {target_name}. Cannot compare.",
247                self._parameters,
248            )
249        self.target = self.multi_targets[target_name]
250        mae = self.compare_against_target(reference, strict_shape)
251        self.target = None
252        return mae
253
254    def matches_target(
255        self, reference: np.ndarray, strict_shape: bool = True, epsilon=0.01
256    ) -> bool:
257        """
258        Compares the given reference image to the target image using Absolute Error (AE).
259
260        :param self: Description
261        :param reference: The reference image to compare.
262        :type reference: np.ndarray
263        :param strict_shape: Whether to error out if the array shapes do not match.
264        :type strict_shape: bool
265        :param epsilon: The threshold for considering a match.
266        :return: True if the AE is below the epsilon threshold, False otherwise.
267        :rtype: bool
268        """
269        mae = self.compare_against_target(reference, strict_shape)
270        if mae <= epsilon:
271            return True
272        return False
273
274    def matches_multi_target(
275        self, target_name: str, reference: np.ndarray, strict_shape: bool = True
276    ) -> bool:
277        """
278        Compares the given reference image to one of the multiple target images using Absolute Error (AE).
279
280        :param target_name: The name of the target image to compare against.
281        :type target_name: str
282        :param reference: The reference image to compare.
283        :type reference: np.ndarray
284        :param strict_shape: Whether to error out if the array shapes do not match.
285        :type strict_shape: bool
286        :return: True if the AE is below the epsilon threshold, False otherwise.
287        :rtype: bool
288        """
289        if self.multi_targets is None or target_name not in self.multi_targets:
290            log_error(
291                f"No multi target image set for NamedScreenRegion {self.name} with target name {target_name}. Cannot compare.",
292                self._parameters,
293            )
294        self.target = self.multi_targets[target_name]
295        result = self.matches_target(reference, strict_shape)
296        self.target = None
297        return result
298
299    def matches_any_multi_target(
300        self, target_names: List[str], reference: np.ndarray, strict_shape: bool = True
301    ) -> bool:
302        """
303        Compares the given reference image to all of the specified target images and returns True if any of them match.
304
305        :param target_names: The names of the target images to compare against.
306        :type target_names: List[str]
307        :param reference: The reference image to compare.
308        :type reference: np.ndarray
309        :param strict_shape: Whether to error out if the array shapes do not match.
310        :type strict_shape: bool
311        :return: True if the AE is below the epsilon threshold for any of the target images, False otherwise.
312        :rtype: bool
313        """
314        for target_name in target_names:
315            if self.matches_multi_target(target_name, reference, strict_shape):
316                return True
317        return False
318
319
320class StateParser(ABC):
321    """
322    Abstract base class for parsing game state variables from the GameBoy emulator.
323    """
324
325    def __init__(
326        self,
327        pyboy,
328        parameters,
329        named_screen_regions: Optional[List[NamedScreenRegion]] = None,
330    ):
331        """
332        Initializes the StateParser. Child implementations should call super().__init__() after running their code.
333            All children must create a self.rom_data_path variable
334        Args:
335            pyboy: An instance of the PyBoy emulator.
336            parameters: A dictionary of parameters for configuration.
337            named_screen_regions (Optional[list[NamedScreenRegion]]): A list of NamedScreenRegion objects for easy access to specific screen regions.
338        """
339        verify_parameters(parameters)
340        self._parameters = parameters
341        if not hasattr(self, "rom_data_path"):
342            log_error(
343                f"StateParsers must define a self.rom_data_path variable pointing to the rom data path for the game variant.",
344                self._parameters,
345            )
346        self.rom_data_path: str = self.rom_data_path
347        """ Path to the rom data directory for the game variant. """
348        if not isinstance(pyboy, PyBoy):
349            log_error("pyboy must be an instance of PyBoy", self._parameters)
350        self._pyboy = pyboy
351        self.named_screen_regions: dict[str, NamedScreenRegion] = {}
352        """ Dictionary of NamedScreenRegion objects for easy access to specific screen regions. """
353        if named_screen_regions is not None:
354            for region in named_screen_regions:
355                if not isinstance(region, NamedScreenRegion):
356                    log_error(
357                        f"named_screen_regions must be a list of NamedScreenRegion objects. Found {type(region)}",
358                        self._parameters,
359                    )
360                if region.name in self.named_screen_regions:
361                    log_error(
362                        f"Duplicate named screen region: {region.name}",
363                        self._parameters,
364                    )
365                self.named_screen_regions[region.name] = region
366        self.image_references = {}
367        """ Dictionary of image references loaded. """
368        location = os.path.join(self.rom_data_path, "image_references")
369        if os.path.exists(location):
370            for file in os.listdir(location):
371                image_path = os.path.join(location, file)
372                if image_path.endswith((".png", ".jpg", ".jpeg")):
373                    reference_name = file.rsplit(".", 1)[0]
374                    image = Image.open(image_path)
375                    self.image_references[reference_name] = image
376                else:
377                    log_warn(
378                        f"Found unsupported image extension {file} in {location}. Only place image files in this folder.",
379                        self._parameters,
380                    )
381
382    @staticmethod
383    def bit_count(bits: int) -> int:
384        """
385        Counts the number of set bits (1s) in the given integer.
386        Args:
387            bits (int): The integer to count set bits in.
388        Returns:
389            int: The number of set bits.
390        """
391        return bin(bits).count("1")
392
393    def read_m(self, addr: bytes) -> int:
394        """
395        Reads a byte from the specified memory address.
396        Args:
397            addr (int): The memory address to read from.
398        Returns:
399            int: The byte value at the specified memory address.
400        """
401        # return self.pyboy.get_memory_value(addr)
402        return self._pyboy.memory[addr]
403
404    def read_bits(self, addr) -> str:
405        """
406        Reads a memory address and returns the result as a binary string. Adds padding so that reading bit 0 works correctly.
407        Args:
408            addr (int): The memory address to read from.
409        Returns:
410            str: The binary string representation of the byte at the specified memory address.
411        """
412        # add padding so zero will read '0b100000000' instead of '0b0'
413        return bin(256 + self.read_m(addr))
414
415    def read_bit(self, addr, bit: int) -> bool:
416        """
417        Reads a specific bit from a memory address.
418        Args:
419            addr (int): The memory address to read from.
420            bit (int): The bit position to read (0-7).
421        Returns:
422            bool: True if the bit is set (1), False otherwise.
423        """
424        # add padding so zero will read '0b100000000' instead of '0b0'
425        return self.read_bits(addr)[-bit - 1] == "1"
426
427    def read_m_bit(self, addr_bit: str) -> bool:
428        """
429        Reads a specific addr-bit string from a memory address.
430        Args:
431            addr_bit (str): The - concatenation of a memory address and the bit position (e.g. '0xD87D-5')
432        Returns:
433            bool: True if the bit at that memory address is set (1), False otherwise
434        """
435        if "-" not in addr_bit:
436            log_error(f"Incorrect format addr_bit: {addr_bit}", self._parameters)
437        addr, bit = addr_bit.split("-")
438        flag = False
439        try:
440            addr = eval(addr)
441        except:
442            flag = True
443        if flag:
444            log_error(
445                f"Could not eval byte string: {addr}. Check format", self._parameters
446            )
447        if not bit.isdigit():
448            log_error(f"bit {bit} is not digit", self._parameters)
449        bit = int(bit)
450        return self.read_bit(addr, bit)
451
452    def get_raised_flags(self, item_dict: dict) -> set:
453        """
454        Reads a dictionary of the form {flag_name: memory_address-bit} and returns a set of all flag names that are currently raised (i.e. the bit at the memory address is 1).
455        Args:
456            item_dict (dict): A dictionary mapping flag names to memory address-bit strings.
457        Returns:
458            set: A set of flag names that are currently raised.
459        """
460        items = set()
461        for item_name, slot in item_dict.items():
462            if self.read_m_bit(slot):
463                items.add(item_name)
464        return items
465
466    def get_current_frame(self) -> np.ndarray:
467        """
468        Reads the pyboy screen and returns a full resolution numpy array
469
470        Returns:
471            np.ndarray: The rendered image as a numpy array.
472        """
473        screen = self._pyboy.screen.ndarray[
474            :, :, 0:1
475        ]  # (144, 160, 3) but force just greyscale
476        return screen.copy()
477
478    @staticmethod
479    def capture_box(
480        current_frame: np.ndarray,
481        start_x: int,
482        start_y: int,
483        width: int,
484        height: int,
485    ) -> np.ndarray:
486        """
487        Captures a rectangular region from the current frame.
488
489        Args:
490            current_frame (np.ndarray): The current frame from the emulator.
491            start_x (int): The starting x-coordinate of the region.
492            start_y (int): The starting y-coordinate of the region.
493            width (int): The width of the region.
494            height (int): The height of the region.
495        Returns:
496            np.ndarray: The captured rectangular region.
497        """
498        # first check that the box is within the frame
499        end_x = start_x + width
500        end_y = start_y + height
501        if (
502            start_x < 0
503            or start_y < 0
504            or end_x > current_frame.shape[1]
505            or end_y > current_frame.shape[0]
506        ):
507            start_x = max(0, start_x)
508            start_y = max(0, start_y)
509            end_x = min(current_frame.shape[1], end_x)
510            end_y = min(current_frame.shape[0], end_y)
511        return current_frame[start_y:end_y, start_x:end_x, :]
512
513    @staticmethod
514    def capture_square_centered(
515        current_frame: np.ndarray, center_x: int, center_y: int, box_size: int
516    ) -> np.ndarray:
517        """
518        Captures a square region from the current frame centered at (center_x, center_y) with the given box size.
519
520        Args:
521            current_frame (np.ndarray): The current frame from the emulator.
522            center_x (int): The x-coordinate of the center of the square.
523            center_y (int): The y-coordinate of the center of the square.
524            box_size (int): The size of the square box to capture.
525
526        Returns:
527            np.ndarray: The captured square region.
528        """
529        half_box = box_size // 2
530        start_x = max(center_x - half_box, 0)
531        end_x = min(center_x + half_box, current_frame.shape[1])
532        start_y = max(center_y - half_box, 0)
533        end_y = min(center_y + half_box, current_frame.shape[0])
534        return current_frame[start_y:end_y, start_x:end_x, :]
535
536    @staticmethod
537    def draw_box(
538        current_frame: np.ndarray,
539        start_x: int,
540        start_y: int,
541        width: int,
542        height: int,
543        color: tuple = (0, 0, 0),
544        thickness: int = 1,
545    ) -> np.ndarray:
546        """
547        Draws a rectangle on the current frame.
548
549        Args:
550            current_frame (np.ndarray): The current frame from the emulator.
551            start_x (int): The starting x-coordinate of the rectangle.
552            start_y (int): The starting y-coordinate of the rectangle.
553            width (int): The width of the rectangle.
554            height (int): The height of the rectangle.
555            color (tuple, optional): The color of the rectangle in BGR format.
556            thickness (int, optional): The thickness of the rectangle border.
557
558        Returns:
559            np.ndarray: The frame with the drawn rectangle.
560        """
561        end_x = start_x + width
562        end_y = start_y + height
563        if (
564            start_x < 0
565            or start_y < 0
566            or end_x > current_frame.shape[1]
567            or end_y > current_frame.shape[0]
568        ):
569            start_x = max(0, start_x)
570            start_y = max(0, start_y)
571            end_x = min(current_frame.shape[1], end_x)
572            end_y = min(current_frame.shape[0], end_y)
573        frame_with_box = current_frame.copy()
574        cv2 = import_cv2(None)
575        cv2.rectangle(
576            frame_with_box, (start_x, start_y), (end_x, end_y), color, thickness
577        )
578        return frame_with_box
579
580    @staticmethod
581    def draw_square_centered(
582        current_frame: np.ndarray,
583        center_x: int,
584        center_y: int,
585        box_size: int,
586        color: tuple = (0, 0, 0),
587        thickness: int = 1,
588    ) -> np.ndarray:
589        """
590        Draws a square on the current frame centered at (center_x, center_y) with the given box size.
591
592        Args:
593            current_frame (np.ndarray): The current frame from the emulator.
594            center_x (int): The x-coordinate of the center of the square.
595            center_y (int): The y-coordinate of the center of the square.
596            box_size (int): The size of the square box to draw.
597            color (tuple, optional): The color of the square in BGR format.
598            thickness (int, optional): The thickness of the square border.
599
600        Returns:
601            np.ndarray: The frame with the drawn square.
602        """
603        half_box = box_size // 2
604        start_x = max(center_x - half_box, 0)
605        end_x = min(center_x + half_box, current_frame.shape[1])
606        start_y = max(center_y - half_box, 0)
607        end_y = min(center_y + half_box, current_frame.shape[0])
608        frame_with_square = current_frame.copy()
609        cv2 = import_cv2(None)
610        cv2.rectangle(
611            frame_with_square, (start_x, start_y), (end_x, end_y), color, thickness
612        )
613        return frame_with_square
614
615    def capture_named_region(self, current_frame: np.ndarray, name: str) -> np.ndarray:
616        """
617        Captures a named region from the current frame.
618
619        Args:
620            current_frame (np.ndarray): The current frame from the emulator.
621            name (str): The name of the region to capture.
622
623        Returns:
624            np.ndarray: The captured region.
625        """
626        if name not in self.named_screen_regions:
627            log_error(f"Named screen region {name} not found.", self._parameters)
628        region = self.named_screen_regions[name]
629        x, y, w, h = region.start_x, region.start_y, region.width, region.height
630        return self.capture_box(current_frame, x, y, w, h)
631
632    def compare_named_region_against_target(
633        self, current_frame: np.ndarray, name: str, strict_shape: bool = True
634    ) -> float:
635        """
636        Computes the Absolute Error (AE) between a named region from the current frame and its target image.
637
638        Args:
639            current_frame (np.ndarray): The current frame from the emulator.
640            name (str): The name of the region to compare.
641            strict_shape (bool, optional): Whether to error out if the array shapes do not match.
642        Returns:
643            float: The Absolute Error (AE) between the named region and its target image.
644        """
645        if name not in self.named_screen_regions:
646            log_error(f"Named screen region {name} not found.", self._parameters)
647        region = self.named_screen_regions[name]
648        captured_region = self.capture_named_region(current_frame, name)
649        return region.compare_against_target(captured_region, strict_shape)
650
651    def named_region_matches_target(self, current_frame: np.ndarray, name: str) -> bool:
652        """
653        Compares a named region from the current frame to its target image using Absolute Error (AE).
654
655        Args:
656            current_frame (np.ndarray): The current frame from the emulator.
657            name (str): The name of the region to compare.
658        Returns:
659            bool: True if the region matches the target image, False otherwise.
660        """
661        if name not in self.named_screen_regions:
662            log_error(f"Named screen region {name} not found.", self._parameters)
663        region = self.named_screen_regions[name]
664        captured_region = self.capture_named_region(current_frame, name)
665        return region.matches_target(captured_region)
666
667    def compare_named_region_against_multi_target(
668        self,
669        current_frame: np.ndarray,
670        name: str,
671        target_name: str,
672        strict_shape: bool = True,
673    ) -> float:
674        """
675        Computes the Absolute Error (AE) between a named region from the current frame and one of its multiple target images.
676
677        Args:
678            current_frame (np.ndarray): The current frame from the emulator.
679            name (str): The name of the region to compare.
680            target_name (str): The name of the target image to compare against.
681            strict_shape (bool, optional): Whether to error out if the array shapes do not match.
682        Returns:
683            float: The Absolute Error (AE) between the named region and the specified target image.
684        """
685        if name not in self.named_screen_regions:
686            log_error(f"Named screen region {name} not found.", self._parameters)
687        region = self.named_screen_regions[name]
688        captured_region = self.capture_named_region(current_frame, name)
689        return region.compare_against_multi_target(
690            target_name, captured_region, strict_shape
691        )
692
693    def named_region_matches_multi_target(
694        self, current_frame: np.ndarray, name: str, target_name: str
695    ) -> bool:
696        """
697        Compares a named region from the current frame to one of its multiple target images using Absolute Error (AE).
698
699        Args:
700            current_frame (np.ndarray): The current frame from the emulator.
701            name (str): The name of the region to compare.
702            target_name (str): The name of the target image to compare against.
703        Returns:
704            bool: True if the region matches the specified target image, False otherwise.
705        """
706        if name not in self.named_screen_regions:
707            log_error(f"Named screen region {name} not found.", self._parameters)
708        region = self.named_screen_regions[name]
709        captured_region = self.capture_named_region(current_frame, name)
710        return region.matches_multi_target(target_name, captured_region)
711
712    def draw_named_region(
713        self,
714        current_frame: np.ndarray,
715        name: str,
716        color: tuple = (0, 0, 0),
717        thickness: int = 1,
718    ) -> np.ndarray:
719        """
720        Draws a named region on the current frame.
721
722        Args:
723            current_frame (np.ndarray): The current frame from the emulator.
724            name (str): The name of the region to draw.
725            color (tuple, optional): The color of the rectangle in BGR format.
726            thickness (int, optional): The thickness of the rectangle border.
727
728        Returns:
729            np.ndarray: The frame with the drawn rectangle.
730        """
731        if name not in self.named_screen_regions:
732            log_error(f"Named screen region {name} not found.", self._parameters)
733        region = self.named_screen_regions[name]
734        x, y, w, h = region.start_x, region.start_y, region.width, region.height
735        return self.draw_box(current_frame, x, y, w, h, color, thickness)
736
737    @staticmethod
738    def draw_grid_overlay(
739        current_frame: np.ndarray, grid_skip: int = 16, x_offset=0, y_offset=-2
740    ) -> np.ndarray:
741        """
742        Draws a grid overlay on the current frame for easier region identification.
743        Args:
744            current_frame (np.ndarray): The current frame from the emulator.
745            grid_skip (int, optional): The number of pixels between grid lines.
746            x_offset (int, optional): The x-offset to apply when drawing the grid.
747            y_offset (int, optional): The y-offset to apply when drawing the grid.
748        Returns:
749            np.ndarray: The frame with the grid overlay.
750        """
751        frame_with_grid = current_frame.copy()
752        cv2 = import_cv2(None)
753        for x in range(0, current_frame.shape[1], grid_skip):
754            cv2.line(
755                frame_with_grid,
756                (x + x_offset, 0),
757                (x + x_offset, current_frame.shape[0]),
758                (0, 0, 255),
759                1,
760                lineType=cv2.LINE_AA,
761            )
762        for y in range(0, current_frame.shape[0], grid_skip):
763            cv2.line(
764                frame_with_grid,
765                (0, y + y_offset),
766                (current_frame.shape[1], y + y_offset),
767                (0, 0, 255),
768                1,
769                lineType=cv2.LINE_AA,
770            )
771        return frame_with_grid
772
773    @staticmethod
774    def capture_grid_cells(
775        current_frame: np.ndarray,
776        *,
777        quadrant: str = None,
778        grid_skip: int = 16,
779        x_offset=0,
780        y_offset=-2,
781    ) -> Dict[Tuple[int, int], np.ndarray]:
782        """
783        Captures all grid cells from the current frame based on the specified grid skip.
784
785        Example:
786        ```python
787        import matplotlib.pyplot as plt
788        # ... run the state_parser in an env, example in dev_play.
789        grid_cells = StateParser.capture_grid_cells(current_frame)
790        keep_keys = [(0, 0), (0, 1)]
791        new_cells = {}
792        for cell in keep_keys:
793            new_cells[cell] = grid_cells[cell]
794        grid_cells = new_cells
795        drawn_frame = self.state_parser.reform_image(grid_cells)
796        quadrants = self.state_parser.get_quadrant_frame(grid_cells=grid_cells)
797        plt.imshow(drawn_frame[:, :, 0], cmap="gray")
798        plt.title(f"Full Screen with Grid Overlay")
799        plt.show()
800        merged = self.state_parser.reform_image(grid_cells)
801        plt.imshow(merged[:, :, 0], cmap="gray")
802        plt.show()
803        ```
804
805        :param current_frame: An emulator frame.
806        :type current_frame: np.ndarray
807        :param quadrant: If specified, only captures cells in the given quadrant ('TL', 'TR', 'BL', 'BR').
808        :type quadrant: str
809        :param grid_skip: The number of pixels between grid lines.
810        :type grid_skip: int
811        :param x_offset: The x-offset to apply when capturing cells.
812        :param y_offset: The y-offset to apply when capturing cells.
813        :return: A dictionary mapping grid cell coordinates to their captured images.
814            The grid cells are with the central cell as (0,0)
815        :rtype: Dict[Tuple[int, int], ndarray[_AnyShape, dtype[Any]]]
816        """
817        if quadrant is not None:
818            if quadrant.lower() not in ["tl", "tr", "bl", "br"]:
819                log_error(
820                    f"Invalid quadrant: {quadrant}. Must be one of 'TL', 'TR', 'BL', 'BR'",
821                )
822        cells = {}
823        if x_offset != 0:
824            x_iter = [-x_offset] + list(range(0, current_frame.shape[1], grid_skip))
825        else:
826            x_iter = list(range(0, current_frame.shape[1], grid_skip))
827        if y_offset != 0:
828            y_iter = [-y_offset] + list(range(0, current_frame.shape[0], grid_skip))
829        else:
830            y_iter = list(range(0, current_frame.shape[0], grid_skip))
831
832        def x_ind(x):
833            index = x_iter.index(x)
834            return (index - (len(x_iter)) // 2) + 1 * (x_offset == 0)
835
836        def y_ind(y):
837            index = y_iter.index(y)
838            return -(index - len(y_iter) // 2) + 1 * (y_offset == 0)
839
840        for x in x_iter:
841            for y in y_iter:
842                x_cell = x_ind(x)
843                y_cell = y_ind(y)
844                if quadrant is not None:
845                    if quadrant.lower() == "tl" and (x_cell > 0 or y_cell < 0):
846                        continue
847                    elif quadrant.lower() == "tr" and (x_cell < 0 or y_cell < 0):
848                        continue
849                    elif quadrant.lower() == "bl" and (x_cell > 0 or y_cell > 0):
850                        continue
851                    elif quadrant.lower() == "br" and (x_cell < 0 or y_cell > 0):
852                        continue
853                cell_image = StateParser.capture_box(
854                    current_frame, x + x_offset, y + y_offset, grid_skip, grid_skip
855                )
856                cells[(x_cell, y_cell)] = cell_image
857        return cells
858
859    @staticmethod
860    def reform_image(grid_cells: Dict[Tuple[int, int], np.ndarray]) -> np.ndarray:
861        """
862        Reform the image from grid cells back into a single image.
863        Expects the grid_cells to correspond to a rectangle.
864        Args:
865            grid_cells (Dict[Tuple[int, int], np.ndarray]): A dictionary mapping (x, y) coordinates to image cells.
866
867        Returns:
868            np.ndarray: The reformed image.
869        """
870        coords = grid_cells.keys()
871        if len(coords) == 1:
872            return list(grid_cells.values())[0]
873        xs = list(set([coord[0] for coord in coords]))
874        ys = list(set([coord[1] for coord in coords]))
875        xs.sort()
876        ys.sort()
877        rows = []
878        for y in ys:
879            row_cells = []
880            for x in xs:
881                row_cells.append(grid_cells[(x, y)])
882            row_image = np.concatenate(row_cells, axis=1)
883            rows.append(row_image)
884        new_rows = []
885
886        if len(rows) == 1:
887            new_rows.append(rows[0])
888        else:
889            # This part is super hacky.
890            # Sometimes, the last and second last row are the exact same. In that case, skip the last row. I don't know man.
891            # show_frames(rows)
892            is_same = rows[-1].shape != rows[-2].shape
893            back_offset = 2 if is_same else 1
894            for item in range(len(rows) - back_offset, -1, -1):
895                new_rows.append(rows[item])
896        full_image = np.concatenate(new_rows, axis=0)
897        return full_image
898
899    def get_quadrant_frame(
900        self, grid_cells: Dict[Tuple[int, int], np.ndarray] = None
901    ) -> Dict[str, Dict[str, Union[np.ndarray, Dict[Tuple[int, int], np.ndarray]]]]:
902        """
903        Divides the current frame or subframe into quadrants and returns groups of quadrants
904
905        :param grid_cells: Subset of grid cells to split. Must be a rectangular box in (x, y) space.
906        :type grid_cells: Dict[Tuple[int, int], np.ndarray]
907        :return: A dictionary where the keys are quadrant keys [tr, tl, br, bl] and values are:
908
909            - screen: which maps to the single numpy array representing that quadrant as a screen
910            - cells: A dictionary mapping cell grids to the specific screen region as numpy arrays.
911        :rtype: Dict[str, Dict[str, Union[np.ndarray, Dict[Tuple[int, int], np.ndarray]]]]
912        """
913        if grid_cells is None:
914            grid_cells = self.capture_grid_cells(self.get_current_frame())
915        coords = grid_cells.keys()
916        xs = list(set([coord[0] for coord in coords]))
917        ys = list(set([coord[1] for coord in coords]))
918        xs.sort()
919        ys.sort()
920        mid_x = xs[len(xs) // 2]
921        mid_y = ys[len(ys) // 2]
922        quadrants = {
923            "tl": {"screen": None, "cells": {}},
924            "tr": {"screen": None, "cells": {}},
925            "bl": {"screen": None, "cells": {}},
926            "br": {"screen": None, "cells": {}},
927        }
928        lower_x = [x for x in xs if x < mid_x]
929        higher_x = [x for x in xs if x >= mid_x]
930        lower_y = [y for y in ys if y < mid_y]
931        higher_y = [y for y in ys if y >= mid_y]
932        for x in lower_x:
933            for y in higher_y:
934                quadrants["tl"]["cells"][(x, y)] = grid_cells[(x, y)]
935        quadrants["tl"]["screen"] = self.reform_image(quadrants["tl"]["cells"])
936        for x in higher_x:
937            for y in higher_y:
938                quadrants["tr"]["cells"][(x, y)] = grid_cells[(x, y)]
939        quadrants["tr"]["screen"] = self.reform_image(quadrants["tr"]["cells"])
940        for x in lower_x:
941            for y in lower_y:
942                quadrants["bl"]["cells"][(x, y)] = grid_cells[(x, y)]
943        quadrants["bl"]["screen"] = self.reform_image(quadrants["bl"]["cells"])
944        for x in higher_x:
945            for y in lower_y:
946                quadrants["br"]["cells"][(x, y)] = grid_cells[(x, y)]
947        quadrants["br"]["screen"] = self.reform_image(quadrants["br"]["cells"])
948        return quadrants
949
950    def get_image_reference(self, reference_name: str) -> Image.Image:
951        """
952        Gets an image reference from the loaded image references.
953        Args:
954            reference_name (str): The name of the image reference to load
955        Returns:
956            Image.Image: The loaded image reference.
957        """
958        if reference_name not in self.image_references:
959            log_error(
960                f"Image reference {reference_name} not found. Available options: {self.image_references.keys()}. If you want to add an image reference, add a file to the image_references folder.",
961                self._parameters,
962            )
963        return self.image_references[reference_name]
964
965    @abstractmethod
966    def __repr__(self) -> str:
967        """
968        Name of the parser for logging purposes.
969        :return: string name of the parser
970        """
971        raise NotImplementedError
972
973
974class DummyParser(StateParser):
975    def __repr__(self) -> str:
976        return "DummyParser"
